Fiberglass Above Ground Water Storage Tanks

fiberglass water storage tanksFiberglass Water Storage Tanks are a reliable, high-strength option for storing, collecting rainwater, distributing and reusing water. Designed from a robust fiberglass fabric, these fiberglass tanks are resistant to rust, corrosion, cracking and denting. This provides customers with a high quality above ground water storage tank that will last for many years.

Construction for these fiberglass water storage tanks includes a careful process of building both the exterior tank and the interior resin. Depending on the type of liquid you will be storing in the tank, resins may be equipped with compliance for drinking water storage, gray water storage or chemicals. When choosing a fiberglass tank, please make sure to let us know what type of liquid will be stored in the tank so we can match the resin to your storage requirements.

Explore financing possibilities for this product; click here to apply for financing!


If you have questions about products, give us a call at 1-863-261-8388 or request a price quote.


Features

  • Exterior features Two-Part Epoxy Covering
  • Interior Fiberglass Resin
  • Material is Inert (only features a one time chemical reaction)
  • Multiple Resins Available
  • Completely Enclosed

Benefits

  • Works to Effectively Store Various Water Types
  • High Resistance to Outside Elements and Interior Liquids
  • High Strength-to-Weight Ratio
  • Prevents Against Rust, Corrosion, Cracking and Deterioration
  • Equipped for Multiple Water Types such as Drinking Water, Gray Water and Rainwater

Standard Applications

  • Water Storage in Homes or Business
  • Emergency Water Supply
  • Fresh Water for Job Sites or in Remote Locations
  • Rainwater Collection
  • Gray Water Storage

Fiberglass Water Storage Tanks Technical Specifications

Capacity
Dimensions
Spill
NTE Weight
525 5' D X 4'8"  501 115
600  4' D X 6'  541 210
1000 4' D X 10'  940 295
900  5' D X 6'  844 22
1525 5' D X 10' 1468 390
1300 6' D X 6'  1216 370
2250 6' D X 10' 2114 472
1750 7' D X 6'  1654 367
3000 7' D X 10' 2887 601
2300 8' D X 6' 2161 485
3950  8' D X 10' 3758 829
2900 9' D X 6'  2735 598
5800 9' D X 10' 4756 1240
3500 10' D X 6'  3376 710
6000 10' D X 10'  5872 1280
4250 11'D X 6' 4085 810
7250 11' D X 10' 7105 1490
5000 12' D X 6' 4862 1400
8600 12' D X 10' 8455 1750
1700 ~7'* X 7'  1623 350

Fiberglass material is extremely flexible and easy to customize. If you need a tank that is a different size than listed above, please give us a call.

*These Tanks Require an Escort for Transportation

All Tanks include Inlet, Outlet, Overflow/Drain, Vent and a 20" Manway

Request a Technical Drawing

Fittings
Standard Fittings are either galvanized (up to 2") or PVC (up to 4")
Flanged Fittings, ABS, or Other Fittings are Considered Specialty and are Extra


Visit our Specialty & Custom Made Tanks page for more options.
In addition to the above ground fiberglass water tank, we also supply underground tanks and fiberglass basins to meet all your liquid storage requirements. For these tanks and additional tank options, check out our Fiberglass Water Storage Tanks.
